A - 13
GENERIC TERMS AND ABBREVIATIONS
Unless otherwise specified, this manual uses the following general terms and
abbreviations.
General term/Abbreviation Description
A/D converter module A generic term for the Q68AD-G and Q66AD-DG
DOS/V personal computer
An IBM PC/AT or compatible computer with DOS/V
GX Developer
The product name of the software package for the MLSEC programmable controllers
GX Works2
GX Configurator-AD
The abbreviation for the analog-digital converter module setting and monitor tool GX Configura-
tor-AD (SW2D5C-QADU-E)
QCPU (Q mode)
A generic term for the Q00JCPU, Q00CPU, Q01CPU, Q02CPU, Q02HCPU, Q06HCPU, Q12HCPU,
Q25HCPU, Q02PHCPU, Q06PHCPU, Q12PHCPU, Q25PHCPU, Q12PRHCPU, Q25PRHCPU,
Q00UJCPU, Q00UCPU, Q01UCPU, Q02UCPU, Q03UDCPU, Q04UDHCPU, Q06UDHCPU,
Q10UDHCPU, Q13UDHCPU, Q20UDHCPU, Q26UDHCPU, Q03UDVCPU, Q04UDVCPU,
Q06UDVCPU, Q13UDVCPU, Q26UDVCPU, Q03UDECPU, Q04UDEHCPU, Q06UDEHCPU,
Q10UDEHCPU, Q13UDEHCPU, Q20UDEHCPU, Q26UDEHCPU, Q50UDEHCPU, and
Q100UDEHCPU.
Process CPU A generic term for the Q02PHCPU, Q06PHCPU, Q12PHCPU and Q25PHCPU
Redundant CPU Generic term for Q12PRHCPU and Q25PRHCPU.
Personal computer A generic term for DOS/V personal computers
Industrial shipment setting
A generic term for analog input ranges 0 to 10V, 0 to 5V, 1 to 5V, -10 to 10V, 0 to 20mA, and 4 to
20mA
FB The abbreviation for function block
