3.4.8 Offset/gain setting mode offset/gain specification (Un\G22,
Un\G23)
(1) Specify the channel to be adjusted for the offset/gain settings.
(2) Specify the channel to be adjusted with an offset value in Un\G22 and the channel to
be adjusted with a gain value in Un\G23.
(3) Set the offset and gain separately (Set either Un\G22 or Un\G23 to 0). If both are set
at the same time, an offset/gain setting mode error (error code 500) occurs.
(4) Refer to Section 4.6 for the details of the offset/gain settings.
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
CH4 CH3 CH2 CH1CH8 CH7 CH6 CH5
1 : Channel set
0 : Invalid
0Un\G23 (Gain specification)
Un\G22 (Offset specification)
0000000
CH4 CH3 CH2 CH1CH8 CH7 CH6 CH500000000
For Q68AD-G, information of b8 to b15 is fixed at 0.
For Q66AD-DG, information of b6 to b15 is fixed at 0.
