3 - 61
3.4 Buffer Memory
3.4.9 Averaging process specification (Un\G24, Un\G25))
3
SPECIFICATIONS
3.4.9 Averaging process specification (Un\G24, Un\G25))
(1) Specify whether to perform sampling processing or averaging processing (time
averaging, count averaging, moving average, or primary delay filter) for each channel.
(2) To validare the setting, the operating condition setting request (Y9) must be turned
ON/OFF. (Refer to Section 3.3.2.)
(3) By default, sampling processing(0
H) is set for all channels.
[Setting example of Q68AD-G]
When setting channel 1 to count averaging, channel 2 to time averaging, channel 3 to
primary delay filter, and channel 4 to sampling processing, store 412
H into Un\G24.
[Setting example of Q66AD-DG]
When setting channel 1 to time averaging, channel 2 to count averaging, channel 3 to
moving average, and channel 4 to primary delay filter, store 4321
H into Un\G24.
When a value outside the above setting range has been written to a channel,
sampling processing is applied to the channel.
Processing method Setting value
Sampling processing 0
H
Time averaging 1H
Count averaging 2H
Moving average 3H
Primary delay filter 4H
b15 b12 b11 b8 b7 b4 b3 b0to to to to
CH8 CH7
CH6
CH5
CH4
Un\G25 (Setting range CH5 to CH8)
Un\G24 (Setting range CH1 to CH4) CH3
CH2
CH1
For Q66AD-DG, information of b8 to b15 is fixed at 0.
b15
CH4 CH3 CH2 CH1
240
412
H
0000010000010010
b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
1
b15
CH4 CH3 CH2 CH1
134
4321
H
0100001100100001
b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
2
