3 - 5
3.1 Performance Specifications
3.1.2 I/O conversion characteristic
3
SPECIFICATIONS
3.1.2 I/O conversion characteristic
The I/O conversion characteristic represents the angle formed by a straight line
connecting the "offset value" and "gain value" when the analog signals (voltage or current
input) from outside the programmable controller are converted to digital values.
Offset value
The offset value denotes the analog input value (voltage or current) that makes the digital
output value 0.
Gain value
The gain value denotes the analog input value (voltage or current) that makes the digital
output value:
4000 (in normal resolution mode)
16000/12000 (in high resolution mode)
