6 - 3
6.2 For Use in Normal System Configuration (Q68AD-G)
6.2.1 Before creating a program
6
PROGRAMMING
6.2.1 Before creating a program
Perform the following steps before creating a program.
(1) Wiring of external devices
Mount the Q68AD-G on the base unit and connect the external devices.
• For all of CH1 to CH3, run the cables for current input.
For details, refer to "4.4.2 (2) (b) For current input".
CH1 external device
CH2 external device
CH3 external device
