4 - 14
4.6 Offset/Gain Settings
4
SETUP AND PROCEDURES BEFORE OPERATION
4.6 Offset/Gain Settings
When using the user range setting, make the offset/gain setting according to the operation
indicated in Section 4.6.1 or Section 4.6.2.
When the Factory default is used, offset/gain setting is not necessary.
If the utility package is installed, perform the offset/gain settings according to the
procedure described in Section 5.6.2.
