6.4.1 Before creating a program
Perform the following steps before creating a program.
(1) Wiring of external devices
Mount the Q68AD-G on the base unit and connect the external devices.
• For all of CH1 to CH3, run the cables for current input.
For details, refer to "4.4.2 (2) (a) For 2-wire transmitter input".
(2-wire transmitter powers)
(2-wire transmitter powers)
(2-wire transmitter powers)
CH1 external device
CH2 external device
CH3 external device
External power supply
FG
24VDC
