App - 13
APPENDIX
Appendix 2 Functions Added or Changed Due to Version Upgrade
The A/D converter has been upgraded with new functions and specifications.
The functions available for use of the A/D converter module vary with the first five digits of
product number.
Also, use the GX Configurator-AD whose version number is compatible one or later.
(1) Q68AD-G
App.1 Q68AD-G
Added or changed
function
Description
Applicable version
Reference
section
First 5 digits
of product
number
GX Configurator-
AD
Analog input range
extended mode
When the following input ranges are selected in the
intelligent function module switch setting, the analog
input ranges can be extended.
• 4 to 20mA (Extended mode)
• 1 to 5V (Extended mode)
The input ranges supported by the analog input range
extended mode cannot be used for products of incom-
patible version.
10062 or later 2.09K or later
Section3.1.1
Section4.5
Input signal error detec-
tion extended setting
When the warning of input signal error detection is
enabled, the input signal error detection can be per-
formed by setting the same value of upper and lower
limit or different value of upper and lower limit.
The input signal error detection cannot be performed by
setting the different value of upper and lower limit, but
can be performed by setting the same value of upper
and lower limit.
Set the buffer memories as follows.
• Un\G47.b15 to b8 Fixed at 0
• Un\G150 to Un\G157 Reserved (system area)
10062 or later 2.09K or later
Section3.2.3
Section3.4.11
Section3.4.22
To Next Page
