SYSTEM CONFIGURATION
2 SYSTEM CONFIGURATION
This chapter explains the system configuration of the A/D converter module.
2.1 Applicable Systems
This section describes the applicable systems.
(1) Applicable modules and base units, and No. of modules
(a) When mounted with a CPU module
For the CPU modules, the number of modules, and base units applicable to the A/
D converter module, refer to the following.
• User's Manual (Hardware Design, Maintenance and Inspection) for the CPU
module used
To use the A/D converter module with a C Controller module, refer to the user's
manual for the C Controller module.
(b) Mounting to a MELSECNET/H remote I/O station
For the number of modules and base units applicable to the A/D converter mod-
ule, refer to the following.
• Q Corresponding MELSECNET/H Network System Reference Manual
(Remote I/O network)
(2) Support of the multiple CPU system
When using the A/D converter in a multiple CPU system, refer to the following manual
first.
• QCPU User's Manual (Multiple CPU System)
(a) Applicable A/D converter module
The A/D converter module is of the function version C from the first product, and
applicable to a multiple CPU system.
(b) Intelligent function module parameters
Write intelligent function module parameters to only the control CPU of the A/D
converter module.
(3) Compatibility with online module change
The A/D converter module is of the function version C from the first product, and
online module change is possible.
For the procedure of online module change, refer to Chapter7.
