3 - 65
3.4 Buffer Memory
3.4.13 Input signal error detection flag (Un\G49)
3
SPECIFICATIONS
3.4.13 Input signal error detection flag (Un\G49)
(1) If the analog input value detected falls outside the setting range sets to the CH input
signal error detection setting value/CH Input signal error detection lower limit setting
value (Un\G142 to Un\G149), or CH input signal error detection upper limit setting
value (Un\G150 to Un\G157), the Input signal error detection flag for the
corresponding channel turns to 1.
(2) By bringing the analog input value within the setting range and turning ON the Error
clear request (YF), the Input signal error detection flag turns OFF.
(3) If an error is detected on any one of the channels for which input signal error detection
is enabled, the Input signal error detection signal (XC) also turns ON.
(4) When the operating condition setting request (Y9) is turned ON, the Input signal error
detection flag is cleared.
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
CH4 CH3 CH2 CH1CH8 CH7 CH6 CH50Un\G49 0 0 0 0 0 0 0
For Q68AD-G, information of b8 to b15 is fixed at 0.
For Q66AD-DG, information of b6 to b15 is fixed at 0.
0: Normal
1: Input signal erro
r
