3 - 59
3.4 Buffer Memory
3.4.6 Write data error code (Un\G19)
3
SPECIFICATIONS
3.4.6 Write data error code (Un\G19)
(1) An error code generated by the A/D converter module is stored here.
(2) Refer to Section 8.1 for details of the error codes.
3.4.7 Setting range (Un\G20, Un\G21)
(1) These areas are used to confirm the input ranges of respective channels.
A value set in the input range setting is stored in the corresponding channel area as
shown below.
Setting ranges of Q68AD-G
Setting ranges of Q66AD-DG
The input range setting cannot be changed in this area.
Change the input range setting in the intelligent function module switch setting.
(Refer to Section 4.5.)
Input range Setting value
4 to 20 mA 0
H
0 to 20 mA 1H
1 to 5 V 2H
0 to 5 V 3H
-10 to 10V 4H
0 to 10 V 5H
4 to 20 mA (Extended mode) AH
1 to 5 V (Extended mode) BH
User range setting FH
Input range Setting value
4 to 20 mA
(For 2-wire transmitter input)
0
H
4 to 20 mA (For current input) 6H
0 to 20 mA (For current input) 7H
4 to 20 mA (Expanded mode)
(For 2-wire transmitter input)
A
H
4 to 20 mA (Expanded mode)
(For current input)
C
H
User range setting
(For current input)
E
H
User range setting
(For 2-wire transmitter input)
F
H
b15 b12 b11 b8 b7 b4 b3 b0to to to to
CH8 CH7 CH6 CH5
CH4
Un\G21(Setting range CH5 to CH8)
Un\G20 (Setting range CH1 to CH4) CH3 CH2 CH1
For Q66AD-DG, information of b8 to b15 is fixed at 0.
