3
SPECIFICATIONS
3.4 Buffer Memory
3.4.23 Mode switching setting (Un\G158, Un\G159)
3 - 74
1
OVERVIEW
2
SYSTEM
CONFIGURATION
3
SPECIFICATIONS
4
SETUP AND
PROCEDURES
BEFORE OPERATION
5
UTILITY PACKAGE
(GX CONFIGURATOR-
AD)
6
PROGRAMMING
7
ONLINE MODULE
CHANGE
8
TROUBLESHOOTING
3.4.23 Mode switching setting (Un\G158, Un\G159)
(1) Set values for the mode desired to be switched to.
(2) After setting the values, turning the operating condition setting request (Y9) from OFF
to ON switches to that mode.
(3) When mode switching is performed, this area is cleared to zero and the operating
condition setting completed flag (X9) turns OFF.
(4) After confirming that the operating condition setting completed flag (X9) has turned
OFF, turn OFF the operating condition setting request (Y9).
If any value other than the above is written, mode switching is not performed and
only the operating condition is changed.
3.4.24 Save data classification setting (Un\G200) (Q68AD-G only)
(1) This area is used to restore the User range settings offset/gain values when the
module is replaced online.
Refer to Chapter 7 for details of online module change.
(2) Specify whether the offset/gain values to be saved/restored are voltages or currents
when saving/restoring the offset/gain values of the user range setting.
Refer to Section 4.6 for the offset/gain value setting method.
Mode to be switched to
Set value
Buffer memory address 158 Buffer memory address 159
Normal mode 0964H 4144H
Offset/gain setting mode 4144H 0964H
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
CH4 CH3 CH2 CH1CH8 CH7 CH6 CH50Un\G200 0 0 0 0 0 0 0
Information of b8 to b15 is fixed to 0.
1: Current
0: Voltage
