7 - 37
7.4 Range Reference Table
7
ONLINE MODULE CHANGE
7.4 Range Reference Table
The range reference tables are given below.
(1) Reference table for offset/gain values of industrial shipment settings
(Un\G202 to Un\G217)
(a) For Q68AD-G
The reference values change depending on the setting of the pass data
classification setting (Un\G200).
(b) For Q66AD-DG
(2) Reference table for user range settings offset/gain values (Un\G218 to
233)
(a) For Q68AD-G
(b) For Q66AD-DG
Example)
When the offset value of the Q68AD-G channel 1 is 1V and its gain value is 5V, the
reference value of the CH1 user range settings offset value (Un\G218) is approxi-
mately 0A3D
H, and the reference value of the CH1 user range settings gain value
(Un\G220) is approximately 3333
H.
Address (Decimal)
Description
Pass data classification
setting (Un\G200)
Reference value
(Hexadecimal)
CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8
202 204 206 208 210 212 214 216
Industrial shipment settings off-
set value
Voltage specified (0V) Approx. 0
H
Current specified (0mA) Approx. 0H
203 205 207 209 211 213 215 217
Industrial shipment settings gain
value
Voltage specified (10V) Approx. 6666
H
Current specified (20mA) Approx. 3333H
Address (Decimal)
Description
Reference value
(Hexadecimal)
CH1 CH2 CH3 CH4 CH5 CH6
202 204 206 208 210 212 Industrial shipment settings offset value
Approx. 0
H
Approx. 0H
203 205 207 209 211 213 Industrial shipment settings gain value
Approx. 6666
H
Approx. 3333H
Offset/gain value Reference value (Hexadecimal)
Voltage
0V Approx. 0
H
1V Approx. 0A3DH
5V Approx. 3333H
10V Approx. 6666H
Current
0mA Approx. 0
H
4mA Approx. 0A3DH
20mA Approx. 3333H
Offset/gain value Reference value (Hexadecimal)
0mA Approx. 0H
4mA Approx. 10E5H
20mA Approx. 547BH
