2
SYSTEM CONFIGURATION
2.1 Applicable Systems
2 - 2
1
OVERVIEW
2
SYSTEM
CONFIGURATION
3
SPECIFICATIONS
4
SETUP AND
PROCEDURES
BEFORE OPERATION
5
UTILITY PACKAGE
(GX CONFIGURATOR-
AD)
6
PROGRAMMING
7
ONLINE MODULE
CHANGE
8
TROUBLESHOOTING
(4) Supported software packages
Relation between the system containing the Q68AD-G and software package is
shown in the following table.
GX Developer or GX Works2 is required to use the A/D converter module.
(1) Depending on the version of GX Configurator-AD, applicable system, CPU
module and functions of A/D converter module vary.
Refer to Appendix 2 for details.
(2) When using GX Works2, refer to the following.
• GX Works2 Version1 Operating Manual (Common)
• GX Works2 Version1 Operating Manual (Intelligent Function Module)
Software Version
GX Developer GX Configurator-AD GX Works2
Q00J/Q00/Q01CPU
Single CPU system Version 7 or later
Version 2.09K or later Refer to the GX Works2
Version1 Operating
Manual (Common)
Multiple CPU system Version 8 or later
Q02/Q02H/Q06H/
Q12H/Q25HCPU
Single CPU system Version 4 or later
Multiple CPU system Version 6 or later
Q02PH/Q06PHCPU
Single CPU system
Version 8.68W or later
Multiple CPU system
Q12PH/Q25PHCPU
Single CPU system
Version 7.10L or later
Multiple CPU system
Q12PRH/
Q25PRHCPU
Redundant CPU system Version 8.45X or later
Q00UJ/Q00U/
Q01UCPU
Single CPU system
Version 8.76E or later
Multiple CPU system
Q02U/Q03UD/
Q04UDH/
Q06UDHCPU
Single CPU system
Version 8.48A or later
Multiple CPU system
Q10UDH/
Q20UDHCPU
Single CPU system
Version 8.76E or later
Multiple CPU system
Q13UDH/
Q26UDHCPU
Single CPU system
Version 8.62Q or later
Multiple CPU system
Q03UDE/Q04UDEH/
Q06UDEH/Q13UDEH/
Q26UDEHCPU
Single CPU system
Version 8.68W or later
Multiple CPU system
Q10UDEH/
Q20UDEHCPU
Single CPU system
Version 8.76E or later
Multiple CPU system
CPU modules other than the above unsupported unsupported
If installed in a MELSECNET/H remote I/O station Version 6 or later Version 2.09K or later
To Next Page
