3.3 I/O Signals for the Programmable Controller CPU
3.3.2 Details of I/O signals
3
SPECIFICATIONS
(2) Output signals
*1: Q66AD-DG only
Device No. Signal Name Description
Y9
Operating
condition setting
request
(1) Turn this signal ON when making any of the following settings valid.
A/D conversion enable/disable setting (Un\G0)
CH Average time/Average number of times/Moving average/Time constant settings
(Un\G1 to Un\G8)
Averaging process specification (Un\G24, Un\G25)
Input signal error detection extended/input signal error detection setting (Un\G47)
Warning output settings (Un\G48)
Scaling enable/disable setting(Un\G53)
CH scaling upper/lower limit value(Un\G62 to Un\G72)
CH conversion starting time setting (for 2-wire transmitter) (Un\G78 to Un\G83)
CH process alarm upper/lower limit value (Un\G86 to Un\G117)
CH rate alarm warning detection period (Un\G118 to Un\G125)
CH rate alarm upper/lower limit value (Un\G126 to Un\G141)
CH input signal error detection setting value/CH input signal error detection lower limit setting
value (Un\G142 to Un\G149)
CH input signal error detection upper limit setting value (Un\G150 to Un\G157)
(2) Refer to the X9 column for ON/OFF timing.
YA
User range writing
request
[In offset/gain setting mode]
(1) This turns ON when the value for the adjusted offset/gain settings are registered in the A/D
converter module.
(2) Refer to the XA column for ON/OFF timing.
Refer to Section 4.6 for offset/gain settings.
[In normal mode]
(1) This signal turns ON when the user range is restored.
(2) Refer to the field of XA for the ON/OFF timing.
Refer to Chapter 7 for user range restoration.
YB
Channel change
request
(1) This turns ON when changing the channel for which offset/gain settings are to be performed.
(2) Refer to the XB column for ON/OFF timing.
Refer to Section 4.6 for offset/gain settings.
YC
Offset/gain
change request
*1
(1) Turn this signal ON when changing the offset/gain value.
(2) Refer to the field of XC for the ON/OFF timing.
Refer to Section 4.6 for the offset/gain setting.
YD
Maximum value/
minimum value
reset request
(1) Turning ON the Maximum value/minimum value reset request (YD) clears the maximum value/
minimum value stored at any of the buffer memory addresses 30 to 45 (Un\G30 to Un\G45).
(2) Refer to the XD column for ON/OFF timing.
YF
Error clear
request
(1) Turn this signal ON when clearing a write error or input signal error.
(2) Refer to the field of XF or XC for the ON/OFF timing.
