3 - 51
3.4 Buffer Memory
3.4.1 Buffer memory assignment
3
SPECIFICATIONS
*1 Indicates whether reading from and writing to a sequence program are enabled.
R : Read enabled
W : Write enabled
*2 When writing data to the buffer memory, always use the interlock condition (buffer memory write
condition) of the following I/O signals.
Table3.9 Buffer memory assignment of Q66AD-DG (2/5)
Address
Description Default
R/W
*1
Reference
Hexadecimal Decimal
1AH 26
System area — — —
to to
1DH 29
1EH 30 CH1 Maximum value 0 R/W
Section 3.4.10
1FH 31 CH1 Minimum value 0 R/W
20H 32 CH2 Maximum value 0 R/W
21H 33 CH2 Minimum value 0 R/W
22H 34 CH3 Maximum value 0 R/W
23H 35 CH3 Minimum value 0 R/W
24H 36 CH4 Maximum value 0 R/W
25H 37 CH4 Minimum value 0 R/W
26H 38 CH5 Maximum value 0 R/W
27H 39 CH5 Minimum value 0 R/W
28H 40 CH6 Maximum value 0 R/W
29H 41 CH6 Minimum value 0 R/W
2AH 42
System area — — —
to to
2EH 46
2FH 47
Input signal error detection extended/input signal error
detection setting
003FH
R/W
*2
Section 3.4.11
30H 48 Warning output setting 3F3FH
R/W
*2
Section 3.4.12
31H 49 Input signal error detection flag 0 R Section 3.4.13
32H 50 Warning output flag (Process alarm) 0 R
Section 3.4.14
33H 51 Warning output flag (Rate alarm) 0 R
34H 52 System area — — —
35H 53 Scaling enable/disable setting 003FH
R/W
*2
Section 3.4.15
36H 54 CH1 Scaling value 0 R
Section 3.4.16
37H 55 CH2 Scaling value 0 R
38H 56 CH3 Scaling value 0 R
39H 57 CH4 Scaling value 0 R
3AH 58 CH5 Scaling value 0 R
3BH 59 CH6 Scaling value 0 R
3CH 60
System area — — —
3DH 61
3EH 62 CH1 Scaling lower limit value 0
R/W
*2
Section 3.4.17
3FH 63 CH1 Scaling upper limit value 0
R/W
*2
40H 64 CH2 Scaling lower limit value 0
R/W
*2
41H 65 CH2 Scaling upper limit value 0
R/W
*2
42H 66 CH3 Scaling lower limit value 0
R/W
*2
43H 67 CH3 Scaling upper limit value 0
R/W
*2
44H 68 CH4 Scaling lower limit value 0
R/W
*2
45H 69 CH4 Scaling upper limit value 0
R/W
*2
Writing
request
Y9 X9
Operating
condition
setting
completed
flag
Operating
condition
setting
request
Buffer memory writing condition
MOV
