Mitsubishi Electric GX Configurator-AD (SW2D5C-QADU-E) User Manual

3 - 63
3.4 Buffer Memory
3.4.11 Input signal error detection extended/input signal error detection setting (Un\G47)
3
SPECIFICATIONS
[Setting example of Q68AD-G]
If the following setting is performed, store 01EA
H into Un\G47.
• The channel 1, 3 and 5 specified for input signal error detection are set to 0
(enabled).
• The channel 1 specified for input signal error detection extended setting is set to
1 (different value of lower and upper limit).
[Setting example of Q66AD-DG]
If the following setting is performed, store 0215
H into Un\G47.
• The channel 2, 4 and 6 specified for input signal error detection are set to 0
(enabled).
• The channel 2 specified for input signal error detection extended setting is set to
1 (different value of lower and upper limit).
b15
CH4 CH3 CH2 CH1CH8 CH7 CH6 CH5
A10
01EA
H
0000000111101010
b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
E
CH4 CH3 CH2 CH1CH8 CH7 CH6 CH5
b15
CH4 CH3 CH2 CH1CH6 CH5
520
0215
H
0000001000010101
b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
1
CH4 CH3 CH2 CH1CH6 CH5
