Mitsubishi AE-200A User Manual

116
WT07627X03
Restrictions on the floor plan files to be read
File size
900 (height) × 1890 (width) dots for each floor plan
Note: The file size must be 900 (height) × 1890 (width) dots regardless of the display range of the area. (Even
when the floor layout shows only one display area, the file size must be 900 (height) × 1890 (width)
dots. In this case, create a file plan only in the left top area.)
File capacity Max. 600 KB for each floor plan
File format
gif
Note: Files that contain extension data (metadata such as XMP, transparent GIF, interlace GIF, animated GIF)
cannot be read.
Available colors
(RGB) to be
used in the file
R G B R G B R G B R G B
224 71 72 101 112 150 130 150 153 176 255 185
221 151 152 126 137 176 105 134 135 238 255 240
81 66 81 142 149 175 37 96 86 154 255 163
105 89 105 175 180 199 204 214 211 198 255 203
17 16 17 33 77 225 48 64 59 106 255 116
51 42 52 37 83 234 250 255 253 137 255 144
27 23 30 39 86 240 227 255 243 226 252 227
165 145 185 41 89 245 241 255 248 124 233 125
33 37 57 42 92 249 237 249 243 250 255 250
2 17 85 46 93 246 67 97 79 167 229 166
6 35 160 23 47 124 59 78 66 107 145 104
6 28 122 63 104 238 61 116 80 182 211 180
9 40 168 77 116 241 85 128 100 23 95 15
12 45 176 99 137 255 154 177 162 149 211 141
154 162 194 126 146 214 14 45 24 128 140 126
211 214 227 149 170 235 59 93 70 95 202 74
15 49 182 70 79 108 178 187 181 194 231 186
17 53 188 179 189 222 46 181 88 147 169 142
20 57 195 191 202 230 59 157 90 41 177 3
24 64 205 192 210 241 90 213 129 166 203 154
17 46 149 163 170 180 214 255 225 208 224 202
21 52 163 236 242 250 224 239 228 219 235 211
28 70 215 159 185 210 129 155 135 172 187 164
32 64 178 144 154 162 178 194 182 203 211 197
45 80 204 204 228 245 115 255 143 241 244 238
44 75 190 112 183 219 99 193 117 199 201 195
55 90 213 126 139 145 182 201 185 110 114 98
69 99 205 214 241 251 59 255 88 127 129 119
99 122 202 159 240 253 19 255 48 210 211 196
R G B R G B R G B R G B
255 253 185 179 159 1 225 148 50 195 195 195
193 193 150 172 169 147 214 159 89 193 193 193
255 255 221 187 185 169 77 76 75 191 191 191
121 121 106 179 177 162 230 211 206 189 189 189
162 162 147 205 203 187 207 203 202 185 185 185
142 142 129 224 222 206 225 197 192 179 179 179
94 94 89 212 201 139 225 8 8 173 173 173
212 212 203 136 134 122 221 179 179 171 171 171
235 235 227 158 156 143 152 151 151 169 169 169
213 213 207 217 215 202 255 255 255 166 166 166
203 203 198 230 228 216 250 250 250 161 161 161
137 137 134 142 128 71 249 249 249 154 154 154
116 116 114 254 246 220 246 246 246 148 148 148
245 245 242 244 237 215 243 243 243 143 143 143
85 85 84 33 25 2 241 241 241 133 133 133
121 121 120 111 110 107 239 239 239 129 129 129
253 253 252 63 43 4 236 236 236 103 103 103
119 117 23 106 104 100 232 232 232 82 82 82
255 253 143 133 132 130 228 228 228 70 70 70
253 241 7 116 79 14 225 225 225 64 64 64
174 173 157 254 251 246 220 220 220 58 58 58
208 195 0 255 151 0 217 217 217 51 51 51
220 210 64 93 61 13 215 215 215 44 44 44
156 153 113 254 221 171 211 211 211 41 41 41
201 199 175 157 97 18 209 209 209 34 34 34
151 150 136 211 205 197 207 207 207 4 4 4
187 175 71 205 128 31 205 205 205 0 0 0
195 193 175 187 116 28 202 202 202 255 170 63
198 197 187 219 138 35 198 198 198 255 203 131
* Use the colors in the table above, otherwise the floor plan will appear in different colors.
* The default background color is RGB [103, 103, 103].
(9) Click [Save] to save the settings.
630 dots
450 dots
1890 dots
900 dots
