205
WT07627X03
11. Explanation of terms
This explains terms used in this manual.
• AE-200 system
This indicates one AE-200 connected to 0 to 4 AE-50/EW-50 expansion controllers.
System configurations are as follows.
■ AE-200 (independent)
A system that does not use an expansion controller.
Use this configuration when not using the apportioned electricity billing function, with up to 50 units managed,
and controlled from the LCD.
■ AE-200
A system that uses 1 to 3 expansion controllers.
Use this configuration when not using the apportioned electricity billing function, with 50 or more units
managed.
■ AE-200 (No M-NET)
A system that uses 1 to 4 expansion controllers.
Use this configuration when not using the apportioned electricity billing function, with 50 or more units
managed, and with the management room far from the indoor units, with electric power not reaching from the
AE-200 to the indoor units.
AE-200
M-NET
AE-200
M-NET
LAN
AE-50/EW-50
M-NET
AE-200
M-NET
LAN
AE-50/EW-50
M-NET
To Next Page
