13
WT07627X03
3. Parts to be used
This section explains parts required for initial settings.
Refer to the Installation Manual for parts required for installation of AE-200/AE-50/EW-50.
3-1. Separately sold parts
Item Qty Description
License Required number
Required to operate functions that require a license.
Register for each of AE-200/AE-50/EW-50.
AE-200 update file
*1
1
Required to ensure that all AE-200/AE-50/EW-50 versions are the same.
If versions do not match, then they will not operate.
AE-50/EW-50 update
file
*1
1
Initial Setting Tool
*1
1
Use to carry out initial settings.
Required when using Integrated Centralized Control Web and apportioned
electricity billing functions.
Depending on the version of AE-200/AE-50/EW-50, the version of the Initial
Setting Tool that can be used will differ.
*2
*1 Contact your dealer regarding the update files.
*2 When performing initial settings using the Initial Setting Tool, it is necessary to ensure that all AE-200/AE-50/EW-50 versions are the same.
Depending on the version of AE-200/AE-50/EW-50, the version of the Initial Setting Tool that can be used will differ as shown in the table
below.
Initial Setting Tool version AE-200/AE-50/EW-50 version .NET Framework
Ver. 1.3 Ver. 7.2–7.5 Ver. 4.5.2 or later
Ver. 1.2 Ver. 7.2–7.4 Ver. 4.5.2 or later
Ver. 1.1 Ver. 7.2–7.3 Ver. 4.5.2 or later
Ver. 1.0 Ver. 7.2 Ver. 4.5 or later
Cannot be used. Ver. 7.1 –
3-2. Commercially available parts
Item Qty Description
PC 1
PC with which to use the Initial Setting Tool and Web Browser for Initial
Settings.
USB memory 1 Required for backup of settings data.
LAN cable Required number
Required for connection of AE-200/AE-50/EW-50 and PC.
Switching HUB Required number
Use a USB memory device that meets the following conditions.
• Supports USB 2.0
• Formatted with FAT32 or FAT (FAT16)
• Security function is not provided or not required to be set.
To Next Page
