97
WT07627X03
6-2-4. Unit address selection screen
On unit address selection screen and group registration screen displayed from the group settings screen, the
selectable unit addresses and groups will be displayed.
When an icon is clicked and selected, the background will change to yellow-green. To deselect an icon, click
the icon again and it will then turn into deselected status (the background will change to light gray). Click [OK]
to complete the selections and close the screen. Click [Cancel] to cancel your selections and close the screen.
Addresses and groups that have already been registered elsewhere will be in gray background and will not be able
to be selected.
On unit address selection screen displayed from the group settings screen, an icon can be changed. To change an
icon, click the icon selection button. Select the desired icon on the group icon selection screen. The selected icon
will be displayed on the AE-200/AE-50’s LCD and in the AE-200/AE-50/EW-50 web browser.
Group other than general equipment group General equipment group
System controller Remote controller AHC
Block settings Refrigerant system (indoor unit) settings,
Interlocked LOSSNAY settings, AI controller
settings
Refrigerant system (outdoor unit) settings
Energy management block settings PI controller settings Metering device settings
6-2-5. Other settings
• Up to 40 characters can be entered as the name on the basic system settings screen. Up to 20 characters
can be entered as names in other setting screens.
• The following characters cannot be used for name settings: <, >, &, “, or ‘
Icon selection
