6
FUNCTIONS
6.7 Input Response Time Selection of Q Series Modules
6
- 36
1
Overview
2
Performance
Specification
3
Sequence Program
Configuration and
Execution Conditions
4
I/O Nunber Assignment
5
Memories and Files
Handled by CPU Module
6
Functions
7
Communication with
Intelligent Function
Module
8
Parameters
(3) Reactions
(a) Restrictions on GX Developer version and the relevant modules
When changing the input response time of the high-speed input module or
interrupt module, use GX Developer version indicated in Table6.14.
If GX Developer version earlier than the version indicated in Table6.14 is used,
the module will operate with the default value of the input response time.
(b) When input response time is shortened
Higher input response time may result in response to inputs being influenced by
noise. Set the desired input response time by taking into consideration the
operating environment of an input module in use.
(c) When AnS series corresponding input module is used
Note6.5
Note5
No change can be made to the input response time of an AnS Series
corresponding input module.
When the input response speed is set to the slot of the AnS series compatible
input module or interrupt module, the settings will be ignored.
(d) Timing when settings are ensured
The input response speed setting is valid in the following cases.
• When the PLC is powered OFF and then ON
• When the CPU module's RESET switch is set to neutral position
Table6.14 Applicable GX Developer version
Module Applicable GX Developer version
High-speed input module GX Developer Version 5 (SW5D5C-GPPW-E) or later
Interrupt module GX Developer Version 6 (SW6D5C-GPPW-E) or later
Note5
Note6.5 Note6.5Note6.5
Basic
Process Redundant
The Basic model QCPU, Process CPU and Redundant CPU do not support the AnS series
corresponding modules.
Basic
Process Redundant
Note6.5 Note6.5Note6.5
