6.11 Monitor Function
6.11.3 Enforced ON/OFF of external I/O
6
FUNCTIONS
(d) Canceling ON/OFF registration information
Note6.15
Note15
ON/OFF registration information can be canceled from GX Developer. Devices for
which enforced ON/OFF has been performed will assume the following statuses
when ON/OFF registered information has been cancelled.
The enforced ON/OFF settings are cleared with the following operations.
• Power supply OFF ON
• Reset with the CPU module RESET/L. CLR switch
• Reset with remote reset operations
Note15
Table6.18 Device statuses after ON/OFF registration information is canceled
Enforced ON/OFF device
ON/OFF performed with
sequence programs
ON/OFF not performed with
sequence programs
Input
Input from modules
mounted on the base unit
Assumes the ON/OFF status received from the module.
Input of CPU module to be
refreshed from LX of
MELSECNET/H module
Assumes the refreshed ON/OFF status from MELSECNET/H.
Input of CPU module to be
refreshed from RX of CC-
Link
Assumes the refreshed ON/OFF status from CC-Link.
Input other than above
(outside of the refresh
range)
Maintains the enforced ON/OFF status.
Output
Output from modules
mounted on the base unit
Outputs the results of the
sequence program operations.
OFF is output.
Output of CPU module to
be refreshed from LX of
MELSECNET/H module
Outputs the results of the
sequence program operations.
OFF is output.
Output of CPU module to
be refreshed from RX of
CC-Link
Outputs the results of the
sequence program operations.
OFF is output.
Output other than above
(outside of the refresh
range)
Assumes the result of the
sequence program operations.
Assumes the OFF status.
Basic
Note6.15
The enforced ON registration and enforced OFF registration cannot be executed for
Basic model QCPU by selecting [Online] [Debug] [Forced input output
registration/cancellation] (
(3) in this section). This operation can be executed for Basic
model QCPU by conducting device test with GX Developer.
