PERFORMANCE SPECIFICATION
2.2 High performance model QCPU
2 - 5
1
Overview
2
Performance Specification
3
Sequence Program Configuration and Execution Conditions
4
I/O Nunber Assignment
5
Memories and Files Handled by CPU Module
6
Functions
7
Communication using built-in Ethernet ports of CPU module
8
Communication with Intelligent Function Module
*5 : Extended by the upgraded functions of CPU module ( Appendix 4.2)
*6 : The CPU module can execute up to 124 programs. The CPU module cannot execute 125 or more programs.
*7 : The number of points can be changed within the setting range. ( Section 10.2)
Table2.2 Performance Specifications
Item
High performance model QCPU
Q02CPU Q02HCPU Q06HCPU Q12HCPU Q25HCPU
Max. number of
files stored
Program memory 28 60 124
252
*6
Memory card (RAM) 287 (When the Q2MEM-2MBS is used)
Memory
card (ROM)
Flash card 288
ATA card 512
Standard RAM
3
*5
Standard ROM 28 60 124 252
No. of times of writing data into the standard
ROM
Max. 100000 times
No. of I/O device points
(No. of points usable on program)
8192 points (X/Y0 to 1FFF)
No. of I/O points (No. of points accessible to
the actual I/O module)
4096 points (X/Y0 to FFF)
No. of device points
Internal relay [M] 8192 points by default (M0-8191) (changeable)
Latch relay [L] 8192 points by default (L0 to 8191) (changeable)
Link relay [B] 8192 points by default (B0 to 1FFF) (changeable)
Timer [T]
2048 points by default (T0 to 2047) (sharing of low- and high-speed timers) (changeable)
The low- and high-speed timers are specified by the instructions.
The measurement unit of the low- and high-speed timers is set up by parameters.
(Low-speed timer: 1 to 1000ms, 1ms unit, 100ms by default)
(High-speed timer: 0.1 to 100ms, 0.1ms unit, 10ms by default)
Retentive timer [ST]
0 point by default (sharing of the low- and high-speed retentive timers) (changeable)
The low- and high-speed retentive timers are specified by the instructions.
The measurement unit of the low- and high-speed retentive timers is set up by parameters.
(Low-speed retentive timer: 1 to 1000ms, 1ms unit, 100ms by default)
(High-speed retentive timer: 0.1 to 100ms, 0.1ms unit, 10ms by default)
Counter [C]
•
Normal counter, 1024 points by default
(C0 to 1023) (changeable)
•
Interrupt counter: 256 points max.
(0 point by default, setting by parameters)
Data register [D] 12288 points by default (D0 to 12287) (changeable)
Link register [W] 8192 points by default (W0 to 1FFF) (changeable)
Annunciator [F] 2048 points by default (F0 to 2047) (changeable)
Edge relay [V] 2048 points by default (V0 to 2047) (changeable)
