2.3.5 Adding User Cards at the BellRFID Module
This step is not part of the initial operation of the system and can
be performed at any time later on. You can skip this step if you do
not intend to use the features described here.
The blue user cards are used by the inhabitants to open the door
without using a key and to listen to mailbox messages directly at the
IP Video Door Station. If the blue function button at the top has not
been installed, make sure that you pay attention to the corresponding
key position for the LED patterns described in the following.
Hold a trained admin card in front of the BellRFID module.
The OK/MENU button at the top right position lights up red.
If you would like to use the keyless entry features and listen to mailbox messages at the
door, press the bell button of the party to which you would like to assign the user card.
The selected button lights up white. If you want to use this card only for opening the door
(i.e., for the nursing service) make sure that you do not press any button now.
Hold the user card in front of the BellRFID module for 5seconds until the module plays a
sound. The LEDs light up in a sequence to confirm that the card has been trained.
If you want to train additional user cards, repeat the steps listed in this section.
Test the trained cards by holding them in front of the BellRFID module one by one. The
electrical door opener should open the door with each card.
