Mold-Masters TempMaster MT - 6.6 Slave Mode

6.6 Slave Mode
Slave mode is an alternative to Manual mode and can be selected if a zone
has a faulty thermocouple. The slaved zone then mimics the same power
output as the healthy zone. If both zones were running at a similar power
level previously, then the slaved zone will hold a similar temperature.
NOTE
Slave mode can only be used between two control zones on the same
module and not across di󰀨erent modules.
1. From the Temperature Display Screen, choose either zone to obtain the
initial menu.
`
2. Choose [
] to obtain the Function menu.
3. Choose [Program] and use [] or [] to nd Slave.
4. Choose [Slave].
6-5
© 2020 Mold-Masters (2007) Limited. All Rights Reserved.
OPERATION
MT Controller User Manual
