9-4

9.2.3 For Four Wire Delta 240V

WARNING

Cable colors may vary. Always wire up according to the cable markings.

NOTE

Delta congurations are supplied with the neutral wire cut from the main

power cord.

Table 9-3 Cable Markings for Four Wire Star

Cable Marking Color Supply Description

R Black Phase 1

S Grey Phase 2

T Brown Phase 3

G Green / yellow Earth

See “9.2.4 Set Power Terminal Block To DELTA Conguration” on page 9-5

for more information.

9-4

WIRING DETAILS

MT Controller User Manual
