Section 9 - Wiring Details
WARNING
Ensure that you have fully read “Section 3 - Safety” before connecting the
controller.
CAUTION
Please take extreme care when connecting the controller to the three-phase
supply. Incorrect connection may appear to work but can result in damage
to the controller.
CAUTION
The following standards only apply to controllers wired to Mold-Masters
standard. Other specications may have been stated when the controller was
ordered. Please refer to the supplied specication details.
9.1 Single Phase Supply Cable
WARNING
Cable colors may vary. Always wire up according to the cable markings.
IMPORTANT
This conguration is only for MT-02-02 controllers.
The three core cable is provided without a mains supply connector. The cable
should be tted with an appropriate connector for the country in which it is
being used.
Table 9-1 Cable Markings for Single Phase Supply Cable (MT-02-02)
Cable Marking Color Supply Description
For 5 wire star or
(Wye 380 VAC)
For 4 wire (Delta 220
VAC)
L Brown Phase Phase 1
N Blue Neutral Phase 2
G Green / yellow Earth Earth
9-1
