9.5.3 MT-02-02 For India
The mold plug of the tool is Han 16 E
®
male insert with Han 16 B
®
double
level housing. See Figure 9-8.
Figure 9-8 Harting Han 16 E
®
insert for MT-02-02
The pin conguration can be found in Table 9-6:
Table 9-6 MT-02-02 Pin Conguration for India
Power Thermocouple
Zone Supply Return Thermocouple + Thermocouple -
1 Pin 9 Pin 10 Pin 1 Pin 2
2 Pin 11 Pin 12 Pin 3 Pin 4
The cut out dimensions are shown in Figure 9-9
Figure 9-9 Harting Han 16 E
®
cut out dimensions
Maximum voltage: 220VAC - 10A.
