9.2 Three Phase Designation

WARNING

Cable colors may vary. Always wire up according to the cable markings.

IMPORTANT

This conguration is for all MT Series controllers except MT-02-02.

The controller is supplied according to your requirements in either a Star or

Delta supply.

9.2.1 Five Wire Star 380VAC

Table 9-2 Cable Markings - 5 Wire Star

Cable Marking Color Supply Description

R Black Phase 1

S Grey Phase 2

T Brown Phase 3

N Blue Neutral

G Green / yellow Earth

See “9.2.2 Set Power Terminal Block to STAR Conguration” on page 9-3

for more information.
