User’s Guide ValueJet 1304

Periodical maintenance

AP-75780 - Revision 1.3 99

5

Clean the Y-rail

Step 1: Open the front cover.

Step 2: clean the Y-rail with a poly-knit wiper.

N° Description

1 Y-rail
