MUTOH ValueJet 1304 - Mode Print; Nozzle Check

User’s Guide ValueJet 1304
Handling the printer
54 AP-75780 - Revision 1.3
4.3.3 Nozzle Check
Used to check whether there are any head clogging, missing nozzles or misfiring nozzles.
4.3.4 Mode Print
Used to confirm the following printing conditions:
 Printmode
 Pre heater set temperature
 Fixer (Platen) heater set temperature
 Drier heater Set temperature
 Adjustment value
Note
 If the nozzle check result indicates that the checked points are blurred or
missing, clean the head. Refer to Open the front cover. on page98
for more
information.
Perform the nozzle check once again after the head has been cleaned.
Note
 For the printing procedure, refer to Test print on page51
Note
 For the printing procedure, refer to Test print on page51
