VJ-1624X/1624WX/1924WX OPERATION MANUAL Before using
3.4 Loading media 85
7. Make sure that the edges of the media is appropriately pressed by Pressurizing rollers.
• When the media is set as shown in the following figure “Not adequate”, follow the procedure to
adjust the position of the roll media.
If the media is set as shown in the following figure “Not adequate”, the media may be misaligned
or creased during printing.
<For VJ-1624X>
No. Name
1 Roll media
2 Pressurizing rollers
No. Name
1 Roll media
2 Pressurizing rollers
1
2
1
2
1
5mm
5mm
5mm
1
222
11
Adequate Not adequate Not adequate
