VJ-1624X/1624WX/1924WX OPERATION MANUAL Before using
3.4 Loading media 99
• The torque is set at either 1kg or 4kg as shown below.
NOTE
• When the torque is set to 4kg, the tension of the media is stronger than when it is set to 1kg.
• If the media gets wrinkled or it comes in contact with Print head after setting the torque to 1kg,
switch it to 4kg.
No. Name
1 Damper lug
1
1
4kg
1kg
