NAiS FP Series Hardware Manual

FP0 Hardware 3.2 Specifications
3-5Matsushita Electric Works (Europe) AG
FP0–E16T/E16P/E8X
Number of
input points
per common
which are
simultaneously
ON
8
5
4
at 24V DC
at 26.4V DC
Ambient temperature (C/F)
34/
93.2
55/
131
43/
109.4
FP0–E32T/E32P/E16X
16
9
8
at 24V DC
at 26.4V DC
Ambient temperature (C/F)
Number of
input points
per common
which are
simultaneously
ON
26/
78.8
55/
131
34/
93.2
3.2.3 Output Specifications
Relay Output Type
FP0 relay output types: E8RS and E16RS
Item Description
Output type
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
Normally open (1 Form A) relay output
Rated control capacity
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
2A 250V AC, 2A 30V DC (4.5A maximum per common)
Output points per E8RS
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
4 points/common
common
E16RS
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
8 points/common
Response time OFF ↔ ON
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
approx. 10ms
ON ↔ OFF
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
approx. 8ms
Mechanical life time
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
20,000,000 operations or more
Electrical life time
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
100,000 operations or more
