Setting Up The Networking Feature
IP Networking
22 â—† Networking
Example:
âž» 11-02-01 : Extension Numbering
Assign the extension numbers to the ports. The extension number can be up to eight digits
long. The Þrst/second digit(s) of the number should be assigned in Program 11-01. This lets
an employee move to a new location (port) and retain the same extension number.
âž» 84-01-xx : CODEC Information Basic Setup
DeÞne the data of H.323 trunks. These settings apply to H.323 Trunks only. Refer to Program
84-12-xx for H.323 extensions and IP networking.
Note that the value of Item 33 (Audio Capability Priority) determines which CODEC settings
to use. This means, for example, that if G.711 is selected in Item 33, the settings in Items 5-12
and 19-21 will be ignored.
System – A System – B
System ID: 1 System ID: 1
IP Address: 172.16.0.11
(from Program 10-12-01)
IP Address: 172.16.0.10
(from Program 10-12-01)
Port: 1730 Port: 1730
Item
No.
Item Input Data Default Description
01 -- Not Used --
02 Number of G711 Audio Frame 2 = 20 ms
3 = 30 ms
3 Maximum number of G711 Audio
Frame
03 G711 Silence Detection Mode 0:Disable
1:Enable
0DeÞne whether the silence detection
enables on G711 or not
04 G711 type 0:A-law
1: u-law
1 Set the type of G711
(A-law or u-law)
05 G729 Audio Frame 1 = 10 ms
2 = 20 ms
3 = 30 ms
4 = 40 ms
5 = 50 ms
6 = 60 ms
7 = 70 ms
8 = 80 ms
3 Maximum number of G729 Audio
Frame
06 G729 0:Disable
1:Enable
0
07 G.729 Jitter Buffer Minimum 0-500 ms 30
08 G.729 Jitter Buffer Type 0-500 ms 60
09 G.729 Jitter Buffer Maximum 0-500 ms 120
10 -- Not Used --
