Setting Up The Networking Feature
IP Networking
Networking â—† 21
âž» 10-27 : IP System ID - IP Address
Set the System ID, IP address, and Call Procedure Port of the networked IP systems.
If setting up a multi-site network, you may wish to deÞne each system the same in this pro-
gram. This will help reduce the confusion if the same ID is programmed in each system. (You
do not need to program the IP address for the system being programmed.) Using the following
sample programming, Network 1 is ID 1, Network 2 is ID 2, Network 3 is ID 3.
Program 10-27-01 Entries
Network 1 Network 2 Network 3
System ID 1
System ID 2
System ID 3
172.16.0.10
172.16.0.11
172.16.0.12
172.16.0.10
172.16.0.11
172.16.0.12
172.16.0.10
172.16.0.11
172.16.0.12
System ID 01-50
Item
No.
Item Input Data Default
Related
Program
01 IP Address
System ID is related
with the System ID in
the Numbering Plan
(Program 11-01-01).
When the digits are
analyzed and the sys-
tem ID is determined
from the system data
set in the Numbering
Plan, the Networking
call will be sent to the
IP Address set in this
program.
The IP Address should
be the IP Address of
the peer NTCPU (Pro-
gram 10-12-01).
1.0.0.1_126.255.255.254
128.1.0.1 _191.254.255.254
192.0.1.1 _223.255.254.254
0.0.0.0 11-01-01
10-12-01
02 Call Procedure Port
The Port Number
should be set with the
same value as the
H.225 setup port in
Program 84-02-33.
1-65535 1730 84-02-33
