Setting Up The Networking Feature
IP Networking
28 ◆ Networking
➻ 84-12-xx : H.323 Phone CODEC Information Basic Setup
Setup the CODEC information of H.323 phones and IP Networking. Refer to Program 84-12-
xx for H.323 extensions and IP networking.
Input Data
Item
No.
Item Input Data Default
Related
Program
01 G711 Audio Frame
Prior to software 2.63, the only entry possible was “2”
or “3”. With software 2.63+, additional entries are
available.
Note: Currently, only the Aspire S system can use the
10ms setting. Aspire will provide this option in the
future.
1 - 3
(1 = 10ms,
2 = 20 ms,
3 = 30ms)
3
02 G711 VAD Mode 0 = Disable
1 = Enable
0
03 G711 Type 0 = A-law
1 = μ-law
1
04 G.711 Jitter Buffer Min 0~145 ms 30
05 G.711 Jitter Buffer Type 0~145 ms 60
06 G.711 Jitter Buffer Max 0~145 ms 120
07 G.729 Audio Frame
Prior to software 2.63, only entries 3-8 were available.
With software 2.63+, additional entries are available.
Note: Currently, only the Aspire S system can use the
10ms setting. Aspire will provide this option in the
future
1-8
(1 = 10ms,
2 = 20ms, etc.)
3
08 G.729 VAD Mode 0 = Disable
1 = Enable
0
09 G.729 Jitter Buffer Min 0~500 ms 30
10 G.729 Jitter Buffer Type 0~500 ms 60
11 G.729 Jitter Buffer Max 0~500 ms 120
12 G.723 Audio Frame 1-2 1
13 G.723 VAD Mode 0 = Disable
1 = Enable
0
14 G.723 Jitter Buffer Min 0~500 ms 30
15 G.723 Jitter Buffer Type 0~500 ms 60
16 G.723 Jitter Buffer Max 0~500 ms 120
