Setting Up The Networking Feature
IP Networking
Networking ◆ 27
➻ 84-02-35 : H.225, H.245 Information Basic Setup - Fast Start Mode
If VoIP is used for networking, the Fast Start option must be enabled.
➻ 84-05-01 : VOIPU IP Address Setup - IP Address
For each VOIPU PCB, enter the IP address for the VOIPU PCB (default: slot 1=172.16.0.20,
slot 2 = 172.16.0.21, etc). The IP address should be increased according to the number of
VOIPU PCBs. This entry becomes invalid if Program 84-04 is set to "1" (DHCP enabled).
Example:
➻ 84-06-10 : VOIPU Setup - DTMF Behavior
Set the DTMF option to “2” when using the networking feature. The system programming
must be exited before these program options to take affect.
Input Data
Item
No.
Item Input Data Default
35 Fast Start 0: Disable
1: Enable
1
Slot Number 01-16
Item Input Data Default Description Related Program
IP
Address
1.0.0.1–126.255.255.254
128.1.0.1–191.254255.254
192.0.1.1–223.255.254.254
Slot 1: 172.16.0.20
Slot 2: 172.16.0.21
Slot 3: 172.16.0.22
Slot 4: 172.16.0.23
Slot 5: 172.16.0.24
Slot 6: 172.16.0.25
Slot 7: 172.16.0.26
Slot 8: 172.16.0.27
Set IP Address of
VoIPU PCB.
IP Address will be
increased in accor-
dance with number of
slot.
84-04
This becomes invalid data
if Program 84-04 is set to
1:Enable.
System – A System – B
IP Address: 172.16.0.20 IP Address: 172.16.0.21
Subnet Mask: 255.255.0.0 Subnet Mask: 255.255.0.0
SLOT Number 01-16
10 DTMF Behavior 0 = DTMF Relay disabled
1 = In-Band DTMF relay,
do NOT report to Host
processor
2 = Out of Band DTMF
relay, do not pass tones as
voice
0 • Inbound - DTMF is transferred by
RTP packets.
• Outbound - DTMF is transferred by
H.245 protocol.
This setting allows DTMF digits to be
relayed between the VOIPU PCBs. It is
recommended that this is set to “1”.
