CHAPTER 3 SYSTEM DATA PROGRAMMING
– 126 – NWA-008853-001 Rev.3.0
97ch3001.fm
DESCRIPTION DATA
Specify the order of LCR selection for the
Route Pattern number assigned by CM8A
Y=4005-4007.
•
(1)
(2)
Y=0000-0255 Route Pattern No. 000-255
1-4: Order of LCR Selection
1: 1st
2: 2nd
3: 3rd
4: 4th
XXX ZZ
XXX: 000-255: LCR Pattern No.
ZZ : 00-63: Trunk Route No.
NOTE: You cannot assign CM8A Y=0000-0255 1st data 0 (Destination of next table) and 1st data
4 (4th LCR selection) simultaneously. The latest data assignment including system data
memory clear is effective. The other assigned data is set as NONE.
Example:
Specify the maximum number of digits to be
dialed by calling party.
The maximum number of digits including the
area codes should be assigned to each area
code.
•
(1)
(2)
Y=5-7 Area Code Development Pattern
No. 5-7 assigned by CM8A
Y=A000
X-X...X: Area code dialed, Maximum 8
digits
01-24 : 1 digit-24 digits
25-79 : 25 digits-79 digits
Assign an ACM signal waiting timer after
sending IAI signal in the outgoing calls via
CCIS to CCH number.
•
(1)
(2)
Y=10
0-7: CCH No.
00-14: 0-28 seconds (2 second increments)
15 : 6 seconds
B
CM8A
Y 1ST DATA 2ND DATA
ORDER OF LCR
SELECTION
0000 0 Destination of next table 0001
1 1st LCR selection 00000 1st LCR selection
2 2nd LCR selection 00101 2nd LCR selection
3 3rd LCR selection 00202 3rd LCR selection
4 4th LCR selection NONE (Unavailable)
0001 0 Destination of next table NONE
1 1st LCR selection 00303 4th LCR selection
2 2nd LCR selection 00404 5th LCR selection
3 3rd LCR selection 00505 6th LCR selection
4 4th LCR selection 00606 7th LCR selection
CM85
CMA7
END
JANUARY/31/2006
DIGITAL CCIS PROGRAMMING
To Next Page
