NEC SL1100 - Figure 1-4 Temporary Code Restriction Override

Start
No
No
Yes
Yes
Should the Temporary
Toll Restriction Override
service code 663 be changed
from the default setting of 775?
Stop
In PRG 20-06-01,
assign Class of
Service to extensions.
In PRG 20-08-06,
enter 0.
In PRG 20-08-06,
enter 1.
Should a user be able
to temporarily override
Toll Restriction
programming?
In PRG 11-11-34,
change the service
code to the desired
entry.
In PRG 21-07-01, for each
extension number, set the 4-digit
password a user dials to override
the Toll Restriction.
In PRG 21-01-07, determine how
long the system should remove
Toll Restriction from the extension.
Figure 1-4 Temporary Code Restriction Override
Operation
To temporarily override a restricted extension Code Restriction:
You can override restriction for only one call at a time.
1. At the Multiline Terminal, press Speaker key.
- OR -
At Single Line Terminal, lift the handset.
2. Dial 775.
ISSUE 2.0
SL1100
Features and Specifications Manual 1-169
