Report Headings Definitions
DATE Date the call was made (PRG 35-02-14= 1 ). For Extension Call this area will be empty.
(V2.0 or higher)
LINE Trunk number used for call. For Extension Call this area will be empty (V2.0 or higher)
DURATION The time the call lasted. (For Transferred calls, shows how long user was on call after an-
swering the Transfer.)
STATION Extension number of call owner (i.e., extension that first placed or answered call) (For
Transferred calls, there can be more than one owner - depending on how many exten-
sions shared the call.)
DIALLED No./CLI For outgoing calls, the number dialed or, for incoming calls, the Caller ID information
ACCOUNT Account Code number entered by extension user For Extension Call this area will be
empty.
Class Definitions
POT Outgoing trunk call
ICM (V2.0 or higher) Extension Call
POTA Outgoing trunk call placed using Toll Restriction Override
PIN Incoming trunk calls
POTP Outgoing trunk call with Personal Code
POTW Outgoing trunk call by using Walking Toll Restriction
ALB All lines in group are busy (group number follows TIME field)
BRD Call blocked due to Toll Restriction
BFL SMDR Buffer Full
NEXT Calling Party Name for previous record
PTRS Transferred call (Incoming/Outgoing)
IVIN BRI/PRI inbound trunk call
IVOT Outgoing BRI/PRI trunk call
IVOTP Outgoing BRI/PRI trunk call with Personal Code
ITRS Transferred BRI/PRI call (Incoming/Outgoing)
SDTA Internal Data Call
IDIN Incoming Tie Line call
IDOT Outgoing Tie Line call
SAD Outgoing call from sensor
WAD Outgoing call form remote inspection
Table 1-67 SMDR Report Format with PRG 35-02-14 Set to ‘0’
Character Position Field Definition
Header Line 1
1~60 Spaces
61~70 MM/DD/YYYY
71 Space
72~75 PAGE
76 Space
77~79 Report page number (e.g., 001)
CR & LF Carriage return and line feed
Header Line 2
1~5 CLASS
ISSUE 2.0 SL1100
Features and Specifications Manual 1-709
