Program
Number
Program Name Description/Comments Assigned Data
22-17-05 Dial-In Conversion Table Area
Setup for Time Pattern - Day of
Week
Assign Day of Week for each DID con-
version table
1-8
1: Sunday
2: Monday
3: Tuesday
4: Wednesday
5: Thursday
6: Friday
7: Saturday
8: Holiday
(default = 1: On (1-8))
Operation
DID calls ring extensions like normal trunk calls.
To Activate DID Call by Time Schedule:
1. At any display Multiline Terminal, press Speaker key.
2. Dial the Dial-In Mode Switching Service Code (Default = Not assigned).
- OR -
Press the Dial-In Mode Switching Programmable Function key (PRG 15-07-01, 88, or SC 751
Key Code 88).
3. Dial 1 ~ 500 (V2.0 or higher) 100 (V1.5 or lower) (table number).
4. Dial the Time Pattern 1~8.
Table 1-15 LED Flash Patterns
Time Pattern LED Appearance
Pattern 1 Off
Pattern 2 On
Pattern 3 Slow Flash
Pattern 4 Fast Flash
Patterns 5~8 Off
SL1100 ISSUE 2.0
1-226
Direct Inward Dialing (DID)
