NEC SL1100 - Table 1-40 Incoming Ringing Tone

Handsfree Answerback/Forced Intercom Ringing:
Program Num-
ber
Program Name Default
20-02-12 System Options for Multiline Telephones - Forced Inter-
com Ring (ICM Call Type)
1
20-06-01 Class of Service for Extensions Extension 101 is Class 15 and other Ex-
tension are Class 1
20-08-10 Class of Service Options (Outgoing Call Service) - Signal/
Voice Call
COS 01~15 = 1
20-09-05 Class of Service Options (Incoming Call Service) - Signal/
Voice Call
COS 01~15 = 1
20-13-06 Class of Service Options (Supplementary Service) - Auto-
matic Off-Hook Signaling (Automatic Override)
COS 01~15 = 1
80-01-01 (28) Service Tone Setup - Tone 28 (Speaker Monitor Tone) Refer to Service tones
(Service Tone #28).
80-01-02 Service Tone Setup - Basic Tone Number Refer to Programming Manual.
82-01-01 Incoming Ring Tone - Frequency 1 Refer to Table 1-40 Incoming Ringing
Tone on page 1-421
Table 1-40 Incoming Ringing Tone
Incoming Ring
Tone Number
Tone
Type
Frequency 1 Frequency 2 Modulation
Pattern 1
(Trunk Incoming)
High
Mid
Low
1100
660
520
1400
760
660
16Hz Modulation
16Hz Modulation
16Hz Modulation
Pattern 2 (Trunk Incom-
ing)
High
Mid
Low
1100
660
520
1400
760
660
8Hz Modulation
8Hz Modulation
8Hz Modulation
Pattern 3
(Trunk Incoming)
High
Mid
Low
2000
1400
1100
760
660
540
16Hz Modulation
16Hz Modulation
16Hz Modulation
Pattern 4
(Trunk Incoming)
High
Mid
Low
2000
1400
1100
760
660
540
8Hz Modulation
8Hz Modulation
8Hz Modulation
Intercom Incoming
Pattern
High
Mid
Low
1100
660
520
1400
760
660
8Hz Modulation
8Hz Modulation
8Hz Modulation
Alarm Sensor Pattern High
Mid
Low
760
760
760
760
760
760
No Charge
No Charge
No Charge
Operation
To place an Intercom call:
1. At Multiline Terminal, press Speaker key.
- OR -
At Single Line Terminal, lift the handset.
ISSUE 2.0
SL1100
Features and Specifications Manual 1-421
