Related Features
ISDN Compatibility
Paging, External
Single Line Terminals
Guide to Feature Programming
The programs listed below indicate the most commonly used programs required for this feature. The
programs are listed in the order that the installer should follow. Refer to the PCPro wizards for further
detailed programming.
• When a * is listed next to the Program Number it indicates a program that MUST be set (from a
default state) for this feature to be enabled.
Program
Number
Program Name/Description Assigned Data
10-03-05 * ETU Setup (SLIU) - 1: Door Phone
The door box requires an unused analog port to be assigned as a
door phone. Only analog ports 3 and 4 on the 084 cards in each KSU
can be used. The first two ports can only be used for analog stations
while the last two can be either an analog station or door box.
0 = SLT
1 = Door Phone
(default = 0)
32-02-01 * Door Box Ring Assignment
Per door box, per day/night mode, assign up to 32 extensions to ring
when the door phone is activated.
Maximum of 8 digits (0 ~ 9,
, #)
(default = 101)
32-03-01 Door Box Basic Setup - Chime Pattern
Per door box specify the chime pattern for ringing.
0 = None
1 ~ 6 = Door Box Ring 1 ~ 6
Defaults:
Door Box 1 = 1
Door Box 2 = 2
Door Box 3 = 3
Door Box 4 = 4
Door Box 5 = 5
Door Box 6 = 6
32-04-01 Door Box Name Setup
Per door box assign a name up to 12 characters long.
Maximum of 12 characters
Defaults:
Door Box 1 = Door-1
Door Box 2 = Door-2
Door Box 3 = Door-3
Door Box 4 = Door-4
Door Box 5 = Door-5
Door Box 6 = Door-6
10-61-01 Relay Type
If the door box requires a relay to activate the door striker assign one
of the relays (1~6) to a type (4): Door Phone.
The relays are on the 084 cards in each KSU.
0 = No Relay
1 = External Music on Hold
2 = BGM Source
3 = External Speaker
4 = Door Phone
(default = 0)
10-61-02 Destination Selection
If PRG 10-61-01 is set to a type (4), this program specifies which door
phone (1 ~ 6) will activate the relay.
0 = Not Used
1 ~ 6 = Door Phone 1 ~ 6
(default = 0)
32-01-01 Door Box Answer Time
A user can answer the door box during the time specified in this pro-
gram.
0 ~ 64800 seconds
(default = 30 seconds)
32-01-02 Door Lock Cancel Time
When a user activates the door lock release relay, this program speci-
fies the amount of time the door strike remains open.
0 ~ 64800 seconds
(default = 10 seconds)
32-03-02 Door Box Basic Setup - Codec Transmit Gain
This program controls the gain levels from the system to the door box.
1 ~ 63 = -15.5 dB ~ +15.5 dB
(default = 32, which is 0 dB)
ISSUE 2.0 SL1100
Features and Specifications Manual 1-255
