DID Call by Day of Week Schedule (Version 2.0 or higher)
DID Call by weekly schedule allows for 500 programmed DID Conversion table entries (PRG
22-17-01, PRG 22-17-05) that can be routed based on Day of Week Patterns. Each DID Conversion
table has a maximum of eight programmable Time Patterns and Day of Week Pattern can reference
one of the 800 different Dial-In Conversion table entries in PRG 22-11-01.
Setting Example)
0:00 0:008:00 17:00
Time Pattern
PRG 22-17
PRG 22-11-01
PRG 22-11-02
1
4
300 Incoming
2
1
101 Incoming
3
4
300 Incoming
Monday - Friday : PRG 22-17-05 : 1 (On)
0:00 0:009:00 15:0013:00
Time Pattern
PRG 22-17
PRG 22-11-01
PRG 22-11-02
1
4
300 Incoming
2
2
102 Incoming
3
3
103 Incoming
4
4
300 Incoming
Saturday : PRG 22-17-05 : 1 (On)
0:00 0:00
Time Pattern
PRG 22-17
PRG 22-11-01
PRG 22-11-02
1
4
300 Incoming
Sunday : PRG 22-17-05 : 1 (On)
PRG 22-11-01 and PRG 22-11-02
Table No. Receive Dial Transfer Dial
1 734 101
2 734 102
3 734 103
