Program
Number
Program Name/Description Assigned Data
14-06-01 Trunk Group Routing
This program is used to setup outbound routing tables to give the ex-
tensions access to the different trunk groups programmed in PRG
14-05-01.
Per Route table there are up to four choices for trunk groups. The low-
est number priority is always selected first and the next priority will not
be selected unless all trunks are unavailable due to a busy condition,
or the circuit card is removed or damaged.
If more than 4 trunk group priorities are required one route table can
be tied to another route table to provide more choices.
0 = No Setting (Calls will not route.)
001 ~ 025 = Trunk Group 1 ~ 25
1001~1025 = Route Table 1 ~ 25
(default = 1)
Alternate Trunk Group Routing
Program
Number
Program Name/Description Assigned Data
11-01-01 * System Numbering
This is the Alternate access code that users will dial to make an out-
bound call on a different trunk group than the Primary trunk group ac-
cess code.
The trunk access code to make alternate calls must be set to a type 4
(special trunk access code).
0 = Not Assigned
1 = Service Code
2 = Extension Number
3 = Trunk Access Code
4 = Special Trunk Access
5 = Operator Access
6 = F-Route Access
9 = Dial Extension Analyze
(Refer to the programming manual for
the default values of all tables.)
11-09-02 * 2nd Trunk Route Access Code
Use this program to assign the alternate trunk access code defined in
PRG 11-01-01. This is the access code that users will dial to make
outbound calls on a different trunk group that the primary trunk group
access code.
Maximum of 4 digits (0 ~ 9,
, #)
(default = 9)
14-05-01 * Trunk Group Setup
Assign all used trunks to valid trunk groups. If trunk group 1 is used
remove all unused trunks out of this trunk group.
Trunk group routing will not be able to access trunks that are assigned
to trunk group 0.
0 ~ 25
(default = 1)
21-15-01 * Individual Trunk Group Routing for Extensions
This assigns extensions per day/night mode to a route table (PRG
14-06-01). This program allows all users to dial the same trunk access
code but access different trunks to make their calls.
0 = No Setting (Calls will not route.)
1 ~ 25 = Route Table 1 ~ 25
(default = 1)
14-06-01 * Trunk Group Routing
This program is used to setup outbound routing tables to give the ex-
tensions access to the different trunk groups programmed in PRG
14-05-01.
Per Route table there are up to four choices for trunk groups. The low-
est number priority is always selected first and the next priority will not
be selected unless all trunks are unavailable due to a busy condition,
or the circuit card is removed or damaged.
If more than 4 trunk group priorities are required one route table can
be tied to another route table to provide more choices.
0 = No Setting (Calls will not route.)
001 ~ 025 = Trunk Group 1 ~ 25
1001~1025 = Route Table 1 ~ 25
(default = 1)
Operation
To place a call using Trunk Group Routing
1. At the Multiline Terminal, press Speaker key.
- OR -
At Single Line Terminal, lift the handset.
2. Dial 0.
ISSUE 2.0
SL1100
Features and Specifications Manual 1-755
