NETGEAR D7000 User Manual

DescriptionField
The SSID is the WiFi network name. If you did not change the SSID, the default SSID displays.
The default SSID is also printed on the product label (see Bottom Panel Product Label on page
17).
We recommend that you do not change the default SSID. If you must change
the SSID, enter a 32-character (maximum), case-sensitive name in this field.
Note
Name (SSID)
From the Channel menu, select Auto for automatic channel selection or select an individual
channel.The default selection is Auto.
In some regions, not all channels are available. Do not change the channel
unless you experience interference (shown by lost connections or slow data
transfers). If this situation occurs, experiment with different channels to see
which is the best.
Note
If you use multiple WiFi access points (APs), reduce interference by selecting
different channels for adjacent APs.We recommend a channel spacing of four
channels between adjacent APs (for example, use Channels 1 and 5, or 6 and
10).
Note
Channel
From the Mode menu, select one of the following modes:
• Up to 54 Mbps. Legacy mode.This mode allows 802.11n, 802.11g, and 802.11b devices to
join the network but limits 802.11n devices to functioning at up to 54 Mbps.
• Up to 289 Mbps. Neighbor-friendly mode for reduced interference with neighboring WiFi
networks.This mode allows 802.11n, 802.11g, and 802.11b devices to join the network but
limits 802.11n devices to functioning at up to 289 Mbps.
• Up to 600 Mbps. Performance mode.This mode allows 802.11n, 802.11g, and 802.11b
devices to join the network and allows 802.11n devices to function at up to 600 Mbps. This
mode is the default mode.
The 600 Mbps performance mode requires 256 QAM support on the WiFi
client.
Note
WPA-PSK security supports speeds of up to 54 Mbps. Even if your devices
are capable of a higher speed, WPA-PSK security limits their speed to 54
Mbps.
Note
Mode
Manage the WiFi Network Settings
97
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000

NETGEAR D7000 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Modulation	PSK
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
Memory card slot(s)	No
Ethernet LAN (RJ-45) ports	5
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
DSL specification	VDSL, VDSL2, ADSL, ADSL2, ADSL2+
Web-based management	-
Firewall security	SPI, NAT
Security algorithms	WPA, WPA2-PSK, WPS
Product type	Tabletop router
Product color	Black
Housing material	Plastic
Flash memory	128 MB
Internal memory	256 MB
Processor cores	2
Processor frequency	1000 MHz
Windows operating systems supported	Windows 2000, Windows 7, Windows 8, Windows Vista, Windows XP
Cables included	LAN (RJ-45), Phone (RJ-11)
Supported network protocols	IPv6
Power source type	AC
Package type	Box

Weight and Dimensions

Depth	185 mm
Width	285 mm
Height	50 mm
Weight	750 g
