NETGEAR ProSafe GS108 User Manual

GS108T Smart Switch Software Administration Manual
5-4 Managing Firmware and Reset Options
v1.0, May 2007
c. Select either Software Image or Boot Code for saving the firmware in the destination file.
If the HTTP mode is selected:
a. Enter the name of the firmware or configuration file to download.
b. Select either Software Image or Load Flash for saving the firmware in the destination
file.
4. Click Apply to start the download.
Factory Reset
Factory Reset enables you reset the switch to its factory default values.
.
1. Click Factory Reset in the blue navigation panel. A screen similar to that shown below
appears.
.
Note: You can also use the Factory Defaults button on the front panel to reset the switch
to its factory default values.
Figure 5-61

NETGEAR ProSafe GS108 Specifications

General

MAC address table	8000 entries
Maximum data transfer rate	1 Gbit/s
Full duplex	Yes
Networking standards	IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Latency	20 μs
Dimensions (WxDxH)	235.5 x 100.8 x 27 mm
Power requirements	5 V @ 2.8 A DC
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet
Switch type	Unmanaged
Basic switching RJ-45 Ethernet ports quantity	8
Noise level	0 dB
Mean time between failures (MTBF)	91.500 h
Power consumption (typical)	14 W
Safety	UL (UL 1950), CUL, C-Tick
LED indicators	Link, Power
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	760 g
