NETGEAR ProSafe GS108 User Manual

3-1
v1.0, May 2007
Chapter 3
Managing System Settings
Using the System Settings Utility
The Navigation Pane on the left hand side of the home page contains a System Menu that enables
you to manage your GS108T Gigabit Smart Switch with features under the following main
headings:
• “Switch Status”
• “IP Access List”
• “Setup”
• “Management Security”
• “MAC Address Table”
• “Time”
• “LLDP”
• “Logs”
The description that follows in this chapter covers these features and tells you how to set them in
the GS108T Smart Switch.
Switch Status
The Switch Status page reports the settings of the configurable parameters of the switch.
1. Click System Status in the blue navigation panel. A screen similar to that shown below
appears.

NETGEAR ProSafe GS108 Specifications

General

MAC address table	8000 entries
Maximum data transfer rate	1 Gbit/s
Full duplex	Yes
Networking standards	IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Latency	20 μs
Dimensions (WxDxH)	235.5 x 100.8 x 27 mm
Power requirements	5 V @ 2.8 A DC
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet
Switch type	Unmanaged
Basic switching RJ-45 Ethernet ports quantity	8
Noise level	0 dB
Mean time between failures (MTBF)	91.500 h
Power consumption (typical)	14 W
Safety	UL (UL 1950), CUL, C-Tick
LED indicators	Link, Power
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	760 g
